Understanding Barlow Lenses for Telescopes

A Barlow lens is an intermediate optical device often utilized between the eyepiece and the objective lens or primary mirror of a telescope. Named after Peter Barlow, a British mathematician, it is commonly identified by its capitalized name.

These lenses come labeled with magnification indicators such as 2x, 3x, and so on. When combined with an eyepiece that yields a 100x magnification, for instance, a 2x Barlow would enhance it to approximately 200x. Generally, for visual purposes, Barlow lenses ranging from 1.5X to 3X are commonly found. Larger than 3X Barlows are typically utilized for astrophotography.

The primary function of a Barlow lens is to increase the magnification provided by any given eyepiece. By inserting a Barlow lens into the optical path of a telescope, one can increase the effective number of magnification choices available with an eyepiece set. This is done economically and can simplify eyepiece needs.

Although often associated with the eyepiece, a Barlow lens is more accurately associated with the optical tube. A Barlow lens is a divergent lens, moving the focal point outward and essentially giving the telescope a longer focal length.

When a telescope has a 400 mm focal length and a 2X Barlow is inserted, it effectively behaves as if it has an 800 mm focal length. As a result, the magnification doubles, as magnification = telescope focal length / eyepiece focal length. This means that each eyepiece can give two magnifications: one with and one without the Barlow.

In practice, Barlow lenses are more frequently discussed in relation to the eyepiece, as it seems more convenient to consider them that way. For example, a 2X Barlow will make a 10mm eyepiece deliver the magnification of a 5mm eyepiece, both yielding a 2x magnification.

One benefit of using a Barlow lens is to take advantage of the longer eye relief typically found in longer focal length, lower power eyepieces. For example, a 30mm Plossl eyepiece has 22mm of eye relief, but a 10mm Plossl may have around 7mm of eye relief for higher magnification. However, if the 30mm Plossl is placed in a 3x Barlow, the equivalent magnification of a 10mm Plossl can be achieved, while still retaining the comfortable 22mm eye relief of the 30mm eyepiece.

Barlow lenses can be found in diverse design configurations. There are conventional models where the eyepiece is inserted into the Barlow lens and then placed into the diagonal or focuser. There are also designs that enable the Barlow's lens housing assembly to be screwed directly onto the eyepiece, often referred to as Barlow elements. These can either be attached to the whole Barlow unit or directly to the eyepiece or the bottom of a camera/adapter.

Quality and performance of Barlow lenses depend on the number and types of lens elements used. Higher-end models may incorporate exotic ED glass types to reduce chromatic aberration and other optical defects. Lens elements can have edge blackening and various coating grades, with "fully multi-coated" being the best. These coatings and blackening techniques are engineered to minimize light loss and internal reflections.

When using a Barlow lens, begin by inserting it into the focuser or the diagonal of your telescope. Introduce the eyepiece into the Barlow once it is securely in place. Refractors, Schmidt-Cassegrains, and Maksutov-Cassegrain telescopes often incorporate a diagonal in the optical path, offering an alternative setup to use a Barlow lens. Here, the Barlow lens is inserted directly into the focuser or visual back, and the diagonal is placed within the Barlow lens. As always, the eyepiece is then placed on the diagonal.

Barlow lenses are not only useful with eyepieces but can also be utilized with cameras for astrophotography. They essentially extend the focal length of the telescope, making them valuable for astrophotography objectives such as lunar or planetary imaging with a DSLR.

Using multiple Barlow lenses, also known as stacking Barlows, may not be straightforward due to the complexities involved in calculating the actual magnification factor. Because of the maximum useful magnification of a telescope and the unknowns associated with stacking Barlows, this practice is seldom necessary.

A Barlow lens can be particularly helpful in several situations: when you don't have an eyepiece at the desired magnification, when you want to retain the long eye relief of a low-power eyepiece at high power, or when you want to stretch your eyepiece budget by effectively doubling your eyepiece set.

New users on a tight budget are often advised to invest in the best Barlow they can afford to provide maximum flexibility at the lowest cost. The ability to achieve higher magnifications without sacrificing viewing comfort makes Barlow lenses an essential addition to any telescope setup.

1. A Barlow lens, named after Peter Barlow, is an intermediate optical device commonly situated between the eyepiece and the objective lens or primary mirror of a telescope, increasing the magnification provided by any given eyepiece.
2. Larger than 3X Barlows are typically employed for astrophotography, providing increased magnification for clearing detailed images of celestial objects such as the moon, planets, or space-and-astronomy related scientists.
3. When a telescope has a 400 mm focal length and a 2X Barlow is inserted, its effective focal length becomes 800 mm, effectively doubling the magnification and providing more options for diverse field of view ranges.
4. Barlow lenses can be found in diverse design configurations, including conventional models featuring an eyepiece inserted into a Barlow lens and then place into the diagonal or focuser, as well as Barlow elements that can be attached to the eyepiece or the bottom of a camera/adapter.
5. Advanced models of Barlow lenses may incorporate exotic ED glass types to reduce chromatic aberration and other optical defects, with "fully multi-coated" coatings being the best option for minimizing light loss and internal reflections.
6. Barlow lenses are not only beneficial with eyepieces but can also be utilized with cameras for astrophotography, extending the focal length of the telescope and aiding in astronomical purposes such as lunar or planetary imaging with a DSLR.
