Grid Stability Exploration: Examining Generators to Reactively-Produced Power
In the intricate world of power grids, managing reactive power is a crucial yet complex task. Reactive power, which causes phase shifts between voltage and current, can lead to voltage swings and frequency oscillations, risking grid blackouts.
The majority of today's power grids still use Alternating Current (AC), despite High-Voltage Direct Current (HVDC) being more economical for long distances. This makes reactive power management an essential part of keeping power grids stable.
One of the key challenges in managing reactive power is the integration of renewables and distributed energy resources (DERs). The growing share of intermittent renewable generation and distributed resources reduces the availability of traditional reactive power sources, complicating grid voltage regulation.
Another challenge is the coordination complexity between Transmission System Operators (TSOs) and Distribution System Operators (DSOs). While TSOs are responsible for managing the transmission grid, DSOs oversee the distribution grid. However, control over DERs is indirect, leading to inefficiencies and challenges in procuring reactive power services cost-effectively.
Several solutions have been developed to address these challenges. Reactive power compensation devices, such as compensation coils, capacitors, shunt-connected Flexible AC Transmission Systems (FACTS) like STATCOMs, and synchronous condensers, provide fast, flexible reactive power support to stabilize voltage.
Advanced inverter functionalities in modern PV inverters and other power electronic devices can produce or absorb reactive power on demand, enhancing grid support without consuming active power.
Smart grid controllers and grid-enhancing technologies (GETs) offer millisecond-level response times to manage reactive power dynamically, improving voltage stability and enabling more reliable integration of renewables.
TSO-DSO coordination frameworks, such as setting voltage stability targets, reactive power setpoints, and economic compensation schemes, encourage efficient utilization of distributed reactive power resources.
Grid code updates and market mechanisms, including introducing droop-like volt-VAr control curves and ancillary service markets for reactive power, encourage consistent and economic reactive power provision from diverse resources.
Power factor correction (PFC) is used to correct low power factors, particularly on inductive loads like electric motors, using capacitors. Tap changers enable fine-grained voltage control in substations.
A power factor (PF) describes the effect of a load on an AC phase. A PF of 1 indicates a purely resistive load, while a PF of 0 indicates a purely reactive load. Shunt reactors and shunt capacitors, along with synchronous condensers, are used for reactive power management.
Transformers always absorb reactive power. Overhead transmission lines start absorbing reactive power if overloaded. Most newly added generating capacity comes from weather-dependent variable generators that use grid-following converters.
Grid operators must synchronize generators with the frequency of AC current, not just a constant voltage. Reactive power flows back to the generator in AC applications, posing problems for grid management. Capacitive and inductive loads are switched in or out to manage reactive power in the grid.
Phase shifts between voltage and current occur in AC grids, necessitating management of reactive power. The switch to AC was finally completed back in 2007. Spinning generators provide AC power and can create or absorb reactive power based on their excitation level. AC power grids consist of multiple generators and consumers, with AC winning the battle of the currents over DC.
